Low profile lifting beam for handling big bags with four lifting eyes. Fits most bags with the measurements of 75x75 cm to 105x105 cm in the bottom.
Design: The attachment points of the bag´s liftingeyes are leveled with the lifting point of the beam - see drawing. The attachment points are extra thick and round to protect the lifting eyes of the big bag and are also designed to prevent the bag from sliding.
Proof: Batch proof 2 x WLL.

  • Material: Plate of high-strength structural steel.
  • Marking: WLL and CE marking.
  • Finish: Yellow painted.
  • Note: Special design lifting beams with negative lifting height for other dimensions of big bags and loads are also manufactured. We also manufacture lifting beams/spreader for simultaneous handling.
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
A
mm
B
mm
E
mm
H
mm
L
mm
K
mm
Weight
kg
CAD
13.356695015 6695 1,5 80 60 62 170 960 25 26
