Green Pin
• Material : drop forged high tensile steel SAE 1035 or 1045
• Safety factor : MBL equals 5 x WLL
• Standard : generally to ASTM F1145-92 formerly U.S. Federal Specification FF-T-791b
• Finish : hot dipped galvanized
• Certification : a works certificate, proof load test certificate and/or EC Declaration of Conformity
can be supplied upon request
  • Ohutustegur: : 5:1
Vali sobiv rida allolevast tabelist ja kliki ostukorvi ikoonile
Tootekood WLL Diameter Thread a inch take up inch Length closed position b
mm
Length open position c
mm
thickness hook d
mm
thickness hook e
mm
opening hook f
mm
Length closed position g
mm
Kaal
kg
11.51SSGPHH1006 0,54 3/8 6 278 415 13 16 15 42 0,53
11.51SSGPHH1209 0,68 1/2 12 456 739 13 19 16 47 1,34
11.51SSGPHH1212 1 1/2 6 305 434 16 22 16 48 0,93
11.51SSGPHH1206 1 1/2 9 380 587 16 22 16 47 1,16
11.51SSGPHH1606 1,02 5/8 6 356 479 16 23 21 67 0,98
11.51SSGPHH1612 1,02 5/8 12 507 784 16 23 21 66 1,71
11.51SSGPHH2506 1,36 3/4 9 468 664 20 27 24 78 1,88
11.51SSGPHH1609 1,59 5/8 9 431 632 20 24 21 67 1,96
11.51SSGPHH1906 2,27 1 6 479 586 26 35 31 109 3,87
11.51SSGPHH1918 2,27 1 18 778 1 191 26 35 31 106 6
11.51SSGPHH2512 2,27 1 24 928 1 495 26 35 31 105 7,52
11.51SSGPHH1909 2,36 3/4 6 393 511 22 27 24 79 1,53
11.51SSGPHH2518 2,36 3/4 12 544 816 22 27 24 78 3,27
11.51SSGPHH2524 2,36 3/4 18 696 1 122 22 27 24 78 4,5
11.51SSGPHH1912 4,54 1 12 625 886 26 35 31 106 6,64
