General: Chain for different applications.


  • Material: Grade 2.
  • Marking: According to standard
  • Finish: 3-4,5 mm zink-platined, 5- mm hot-dip galvanized.
  • Standard: DIN 763
  • Warning: Not for lifting.
  • Grade: 2
Select a row from the table below, then click the add to quote button
Part Code Code Diameter
mm
Min. breakingforce
kN
Length
m
Breaking force
kP
E
mm
H
mm
Weight
kg/m
CAD
11.60763030ER50 LLZ-3-D2 3 3,2 50 326 26 6 0,15
11.60763040ER50 LLZ-4-D2 4 6 50 612 32 8 0,27
11.60763050ER30 LLZ-5-D2 5 10 30 1 020 35 10 0,43
11.60763060ER30 LLZ-6-D2 6 14 30 1 441 42 12 0,63
11.60763080ER15 LLZ-8-D2 8 25 15 2 549 52 16 1,1
11.60763100ER15 LLZ-10-D2 10 35 15 4 079 65 20 1,8
*Please note that this product is sold only in rolls.
