Green Pin
• Material : drop forged high tensile steel SAE 1035 or 1045
• Safety factor : MBL equals 5 x WLL
• Standard : generally to ASTM F1145-92 formerly U.S. Federal Specification FF-T-791b
• Finish : hot dipped galvanized
• Certification : a works certificate, proof load test certificate and/or EC Declaration of Conformity
can be supplied upon request
  • Ohutustegur: : 5:1
Vali allolevast tabelist sobivaim rida, seejärel lisa toode päringule
Tootekood WLL
tonn
Diameter Thread a inch Poldi Ø (mm) take up inch Length closed position b (mm) Length open position c (mm) Length closed position d (mm) opening jaw e (mm) thickness jaw eye h (mm) diameter jaw eye i (mm) length inside f Kaal
kg
CAD
11.51SSGPGG1006 0,54 3/8 7 6 273 409 304 12 9 21 21 0,55
11.51SSGPGG1206 1 1/2 10 6 304 435 343 16 11 25 26 0,96
11.51SSGPGG1209 1 1/2 10 9 379 588 418 16 11 25 26 1,18
11.51SSGPGG1212 1 1/2 10 12 455 740 494 16 11 25 26 1,5
11.51SSGPGG1606 1,59 5/8 13 6 346 469 406 18 14 33 32 1,75
11.51SSGPGG1609 1,59 5/8 13 9 421 622 480 18 14 33 32 2,14
11.51SSGPGG1612 1,59 5/8 13 12 498 774 557 18 14 33 32 2,43
11.51SSGPMBGG1906 2,36 3/4 16 6 369 487 439 24 16 41 38 2,7
11.51SSGPMBGG1909 2,36 3/4 16 9 444 640 514 24 16 41 38 3,23
11.51SSGPMBGG1912 2,36 3/4 16 12 520 792 590 24 16 41 38 3,57
11.51SSGPMBGG1918 2,36 3/4 16 18 670 1 096 740 24 16 41 38 4,55
11.51SSGPMBGG2212 3,27 7/8 19 12 561 826 638 27 19 48 42 5,22
11.51SSGPMBGG2218 3,27 7/8 19 18 713 1 132 790 27 19 48 42 6,56
11.51SSGPMBGG2518 4,5 1 22 24 903 1 470 988 31 20 54 50 8,9
11.51SSGPMBGG2524 4,54 1 22 6 447 554 532 31 20 54 50 5,54
11.51SSGPMBGG2506 4,54 1 22 12 598 859 683 31 20 54 50 6,96
11.51SSGPMBGG2512 4,54 1 22 18 750 1 168 835 31 20 54 50 8,4
11.51SSGPMBGG3212 6,9 1 1/4 28 12 643 916 748 44 26 68 71 11,9
11.51SSGPMBGG3218 6,9 1 1/4 28 18 805 1 230 910 44 26 68 71 13,6
11.51SSGPMBGG3224 6,9 1 1/4 28 24 964 1 541 1 069 44 26 68 71 14,2
11.51SSGPMBGG3812 9,71 1 1/2 35 12 675 942 806 52 28 80 71 18,5
11.51SSGPMBGG3818 9,71 1 1/2 35 18 825 1 244 956 52 28 80 71 19,3
11.51SSGPMBGG3824 9,71 1 1/2 35 24 980 1 551 1 111 52 28 80 71 22
11.51SSGPMBGG4518 12,7 1 3/4 41 18 938 1 310 1 092 60 33 90 86 30
11.51SSGPMBGG4524 12,7 1 3/4 41 24 1 089 1 621 1 243 60 33 90 86 33
11.51SSGPMBGG5024 16,8 2 50 24 1 153 1 673 1 338 63 40 107 93 50
11.51SSGPMBGG6424 27,2 2 1/2 57 24 1 255 1 831 1 480 75 41 143 114 92
11.51SSGPMBGG6924 34 2 3/4 70 24 1 348 1 882 1 604 90 41 158 110 109
