Ropeblock

The Ropeblock closed spelter socket CSS designed with mechanical values (Charpy-V > 42 joule / - 20° C) for though and low temperature use.
All sockets have a 100% efficency on the MBL of the steel wire rope but are limited to the MBL of the socket.

The CSS sockets are Type Approved by DNV and Lloyd’s Register.

CSS 296 until CSS 201 only available with hot dipped galvanized finish.

  • Material: Quenched and tempered cast steel.
  • Marking: According to standard, CE-marked
  • Temperature range: - 40°C to + 110°C - Use at higher temperatures possible with reduction of WLL.
  • Finish: Hot dipped Galvanized (G) or painted blue (P).
  • Standard: EN 10204
Select a row from the table below, then click the add to cart button
Part Code MBL For wire Ø
mm
Strand Ø
mm
Finish TL
mm
TA
mm
A
mm
B
mm
C
mm
Ø H
mm
K
mm
T
mm
Weight
kg
CAD
10.10CSS296.GAL 8 6-7 G 101 37 50 40 11 9,1 22 13 0,3
10.10CSS297.GAL 12 8-10 G 119 43 57 48 14 12,6 25 18 0,5
10.10CSS298.GAL 20 11-13 G 140 51 64 59 17,5 14,6 30 23 0,7
10.10CSS299.GAL 25 14-16 13 G 162 67 76 65 21 18,1 36 26 1,4
10.10CSS200.GAL 40 18-19 14-16 G 194 76 89 78 27 21,9 42 32 2,2
10.10CSS201.GAL 55 20-22 18-19 G 224 92 101 90 33 24,9 47 38 3,8
10.10CSS204 75 23-26 20-22 P 253 104 114 103 36 28,8 57 44 5,4
10.10CSS204.GAL 75 23-26 20-22 G 253 104 114 103 36 28,8 57 44 5,4
10.10CSS207.GAL 90 27-30 23-26 G 282 114 127 116 39 32,9 65 51 7
10.10CSS207 90 27-30 23-26 P 282 114 127 116 39 32,9 65 51 7
10.10CSS212.GAL 125 31-36 27-28 G 312 126 139 130 43 39,2 71 57 10
10.10CSS212 125 31-36 27-28 P 312 126 139 130 43 39,2 71 57 10
10.10CSS215 150 37-39 30-32 P 358 136 152 155 51 42,5 81 63 13
10.10CSS215.GAL 150 37-39 30-32 G 358 136 152 155 51 42,5 81 63 13
10.10CSS217 170 40-42 33-35 P 390 146 165 171 54 45,5 83 70 17
10.10CSS217.GAL 170 40-42 33-35 G 390 146 165 171 54 45,5 83 70 17
10.10CSS219 225 43-48 36-40 P 443 171 190 198 55 52,5 93 76 26
10.10CSS219.GAL 225 43-48 36-40 G 443 171 190 198 55 52,5 93 76 26
10.10CSS222 280 49-54 42-45 P 502 193 216 224 62 59,1 100 82 37
10.10CSS222.GAL 280 49-54 42-45 G 502 193 216 224 62 59,1 100 82 37
10.10CSS224.GAL 360 55-60 46-48 G 548 216 228 247 73 65,1 112 92 50
10.10CSS224 360 55-60 46-48 P 548 216 228 247 73 65,1 112 92 50
10.10CSS226.GAL 425 61-68 50-54 G 257 241 248 270 79 73,4 140 102 66
10.10CSS226 425 61-68 50-54 P 257 241 248 270 79 73,4 140 102 66
10.10CSS227 460 69-75 56-62 P 644 273 279 286 79 79,4 159 124 91
10.10CSS227.GAL 460 69-75 56-62 G 644 273 279 286 79 79,4 159 124 91
10.10CSS228 560 76-80 64-67 P 696 292 315 298 83 88,2 171 133 117
10.10CSS228.GAL 560 76-80 64-67 G 696 292 315 298 83 88,2 171 133 117
10.10CSS229.GAL 625 81-86 69-76 G 743 311 330 311 102 92,4 184 146 125
10.10CSS229 625 81-86 69-76 P 743 311 330 311 102 92,4 184 146 125
10.10CSS230.GAL 720 87-93 78-86 G 788 330 356 330 102 98,8 197 159 176
10.10CSS230 720 87-93 78-86 P 788 330 356 330 102 98,8 197 159 176
10.10CSS231.GAL 875 94-102 88-96 G 845 362 381 356 108 107,8 216 178 228
10.10CSS231 875 94-102 88-96 P 845 362 381 356 108 107,8 216 178 228
10.10CSS233.GAL 1 200 108-115 98-110 G 1 000 405 450 425 125 129,5 235 190 323
10.10CSS233 1 200 108-115 98-110 P 1 000 405 450 425 125 129,5 235 190 323
10.10CSS240 1 400 120-130 112-124 P 1 150 450 500 525 125 147,1 260 200 447
10.10CSS240.GAL 1 400 120-130 112-124 G 1 150 450 500 525 125 147,1 260 200 447
10.10CSS245.GAL 1 600 135-140 125-132 G 1 185 520 540 495 150 153,9 290 220 645
10.10CSS245 1 600 135-140 125-132 P 1 185 520 540 495 150 153,9 290 220 645
10.10CSS250 2 000 142-153 133-143 P 1 285 545 585 530 170 171,1 305 240 741
10.10CSS250.GAL 2 000 142-153 133-143 G 1 285 545 585 530 170 171,1 305 240 741
10.10CSS255 2 220 154-165 144-154 P 1 370 575 630 565 175 185,1 330 250 860
10.10CSS255.GAL 2 220 154-165 144-154 G 1 370 575 630 565 175 185,1 330 250 860
10.10CSS260.GAL 2 500 166-178 155-166 G 1 450 595 680 590 180 199,1 330 270 985
10.10CSS260 2 500 166-178 155-166 P 1 450 595 680 590 180 199,1 330 270 985
10.10CSS265.GAL 2 800 180-191 167-179 G 1 535 625 725 620 190 213 350 290 1 183
10.10CSS265 2 800 180-191 167-179 P 1 535 625 725 620 190 213 350 290 1 183
10.10CSS270 3 200 192-204 180-191 P 1 635 690 775 650 210 228,5 395 305 1 487
10.10CSS270.GAL 3 200 192-204 180-191 G 1 635 690 775 650 210 228,5 395 305 1 487

Finish G = hot dipped Galvanized
Finish P = Painted RAL 5013 blue

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
