General: Lifting beam for handling standard 20-ft and 40-ft containers. Supplied complete with wire rope or chain slings, type CLB-32 or CLB-40 container hooks for attachment to container bottom fixings and type CLT for top fixings.
Design: The type C frame beam is designed for lifting from the bottom fixings. The type D frame beam is designed for lifting from the top fixings.
Proof: 1.5 x WLL.
Type C Frame beam - bottom lift.
Type D Frame beam - top lift.

  • Material: Hollow-beam and plate of high-strength structural steel.
  • Marking: Maximum load and CE mark.
  • Finish: Painted (yellow).
  • Note: Manufactured in accordance with the Swedish and international standard SS-ISO 3874, which states that a lifting beam is required when handling loaded standard containers larger than 10 ft in
6690
LYFTCM_e_225mm
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
Type For container size (ft) B
mm
H
mm
K
mm
L
mm
Weight
kg
CAD
13.35xxxx 6692D-240 24 1C-1CC 20 2 260 3 600 1 100 5 850 690
13.35xxxx 6692C-240 24 1C-1CC 20 2 550 3 650 3 400 5 850 720
13.35xxxx 6694D-360 36 1A-1AAA 40 2 260 6 500 1 300 11 985 2 350
13.35xxxx 6694C-360 36 1A-1AAA 40 2 550 6 500 3 800 11 985 2 400
