For lashing and load security of heavy loads on trucks and rail. 25% higher lashing capacity than grade 8 Clevis turnbuckles.

  • Material: Alloy steel grade 10.
  • Marking: According to standard, Pewag or PW, winner 10, H16, CE, batch code and type.
  • Finish: Orange powder coated.
  • Standard: EN 12195-3
  • Safety factor: 2:1.
  • Grade: 10
Clevis turnbuckle for lashing chain
Clevis turnbuckle for lashing chain
Select a row from the table below, then click the add to cart button
Part Code Code LC
kN
STF
daN
Tension distance L closed L open D
mm
Weight
kg
CAD
14.1073217 KKSW 16 200 - 250 530 780 20 10
