Thimbles are use as protection of steel wire rope loops.

Design: Forged.

  • Marking: According to standard
  • Finish: Galvanized
  • Standard: EN 13411-1
    DIN 3090 replaced by EN 13411-1
4921_e_225mm
4921m_e _225mm
Select a row from the table below, then click the add to cart button
Part Code Rope diameter
mm
A
mm
L
mm
B
mm
C
mm
Weight
kg/100m
CAD
10.25309006 6 15 30 10 7 3
10.25309008 8 20 40 13 9 7,1
10.25309010 10 25 50 15 11 17
10.25309012 12 30 60 19 13 24
10.25309014 14 35 70 22 16 36
10.25309016 16 40 80 25 18 50
10.25309018 18 45 90 27 20 62
10.25309020 20 50 100 30 22 90
10.25309022 22 55 110 33 24 100
10.25309024 24 60 120 35 26 130
10.25309026 26 65 130 45 29 220
10.25309028 28 70 140 48 31 240
10.25309032 32 80 160 50 35 270
10.25309036 36 90 180 55 40 430
10.25309040 40 100 200 60 44 570
10.25309044 44 110 220 68 48 850
10.25309048 48 120 240 72 53 1 120
10.25309052 52 130 260 80 57 1 530
10.25309056 56 140 280 83 62 2 148
10.25309060 60 150 300 90 66 2 300
10.25309068 68 170 340 100 75 3 700
