General: Intended for attaching of wire rope where switching often occur, e.g. blocks of mobilecranes, or to be able to adjust the length of the wire rope. See recommended assembly to get correct results.
Design: The wedge socket is delivered complete.

Marking house and wedge: Dimension area.
Finish: Blue painted or hot dip galvanized (OWS 0.25 to 0.5 is standard delivered with galvanized finish) / Pin or bolt.

The dead end should have a length of 6 times the wire dia. with a minimum of 150mm.

Materjal: Cast alloy steel with high mechanical properties.
Märkus: The efficiency of a 6 and 8 strand wire rope/wedge socket connection is 80% of the minimum breaking load of the wire but limited to the minimum breaking load of the socket (MBL).

Vali allolevast tabelist sobivaim rida, seejärel lisa toode päringule

Tootekood	Kood	MBL ton	Trossi Ø (mm)	Pinnakate	TB (mm)	TL (mm)	A (mm)	B (mm)	C (mm)	Ø P (mm)	T (mm)	W (mm)	Kaal kg
02.170708HOL	OWS 0,25 P	8	7-8	P	51	128	110	18	36	16	9	18	0,8
10.20OWS0025PGAL	OWS 0,25 P	8	7-8	G	51	128	110	18	36	16	9	18	0,8
	OWS 0.25 B	8	7-8	G	62	128	110	18	36	16	9	18	0,8
	OWS 0.25 B	8	7-8	P	62	128	110	18	36	16	9	18	0,8
10.20OWS005PGAL	OWS 0,5 P	12	9-10	G	63	165	145	23	46	20,6	11	20,5	1,7
	OWS 0.5 B	12	9-10	G	75	168	145	23	46	20,6	11	20,5	1,7
	OWS 0.5 B	12	9-10	P	75	168	145	23	46	20,6	11	20,5	1,7
02.170910HOL	OWS 0,5 P	12	9-10	P	63	165	145	23	46	20,6	11	20,5	1,7
	OWS 1 B	20	11-13	P	80	174,5	146	28,5	57	25	12	25	2,1
	OWS 1 B	20	11-13	G	80	174,5	146	28,5	57	25	12	25	2,1
02.171113HOL	OWS 1 P	20	11-13	P	67	174,5	146	28,5	57	25	12	25	2,1
10.20OWS01PGAL	OWS 1 P	20	11-13	G	67	174,5	146	28,5	57	25	12	25	2,1
	OWS 2 B	25	14-16	G	96	211	176	35	70	30	15	31	4
	OWS 2 B	25	14-16	P	96	211	176	35	70	30	15	31	4
10.20OWS02PGAL	OWS 2 P	25	14-16	G	85	211	176	35	70	30	15	31	4
02.171416HOL	OWS 2 P	25	14-16	P	85	211	176	35	70	30	15	31	4
	OWS 3 B	40	18-19	G	107	250	210	40	80	35	16	38	7
	OWS 3 B	40	18-19	P	107	250	210	40	80	35	16	38	7
10.20OWS03PGAL	OWS 3 P	40	18-19	G	95	250	210	40	80	35	16	38	7
02.171819HOL	OWS 3 P	40	18-19	P	95	250	210	40	80	35	16	38	7
	OWS 4 B	55	20-22	P	123	285	237,5	47,5	95	41	18	44	10
02.172022HOL	OWS 4 P	55	20-22	P	110	285	237,5	47,5	95	41	18	44	10
10.20OWS04PGAL	OWS 4 P	55	20-22	G	110	285	237,5	47,5	95	41	18	44	10
	OWS 4 B	55	20-22	G	123	285	237,5	47,5	95	41	18	44	10
	OWS 5 B	75	24-26	P	138	330	275	55	110	51	22	51	15
02.172426HOL	OWS 5 P	75	24-26	P	128	330	275	55	110	51	22	51	15
	OWS 5 B	75	24-26	G	138	330	275	55	110	51	22	51	15
10.20OWS05PGAL	OWS 5 P	75	24-26	G	128	330	275	55	110	51	22	51	15
	OWS 6 B	90	27-29	G	160	375	310	65	130	57	25	57	21
10.20OWS06PGAL	OWS 6 P	90	27-29	G	142	375	310	65	130	57	25	57	21
02.172729HOL	OWS 6 P	90	27-29	P	142	375	310	65	130	57	25	57	21
	OWS 6 B	90	27-29	P	160	375	310	65	130	57	25	57	21
	OWS 7 B	110	30-32	G	165	423	350	73	146	64	28	63	31
10.20OWS07PGAL	OWS 7 P	110	30-32	G	155	423	350	73	146	64	28	63	31
02.173032HOL	OWS 7 P	110	30-32	P	155	423	350	73	146	64	28	63	31
	OWS 7 B	110	30-32	P	165	423	350	73	146	64	28	63	31
10.20OWS08PGAL	OWS 8 P	125	34-36	G	160	474	400	74	148	64	28	70	37
	OWS 8 B	125	34-36	G	185	474	400	74	148	64	28	70	37
02.173436HOL	OWS 8 P	125	34-36	P	160	474	400	74	148	64	28	70	37
	OWS 8 B	125	34-36	P	185	474	400	74	148	64	28	70	37
02.173739HOL	OWS 9 P	150	37-39	P	177	530	450	80	142	70	30	77	51
	OWS 9 B	150	37-39	G	201	530	450	80	142	70	30	77	51
	OWS 9 B	150	37-39	P	201	530	450	80	142	70	30	77	51
10.20OWS09PGAL	OWS 9 P	150	37-39	G	177	530	450	80	142	70	30	77	51
02.174042HOL	OWS 10 P	170	40-42	P	187	587	500	87	160	76	33	76	64
	OWS 10 B	170	40-42	P	209	587	500	87	160	76	33	76	64
	OWS 10 B	170	40-42	G	209	587	500	87	160	76	33	76	64
10.20OWS10PGAL	OWS 10 P	170	40-42	G	187	587	500	87	160	76	33	76	64
02.174248HOL	OWS 11 P	225	43-48	P	215	650	550	100	186	89	39	89	96
	OWS 11 B	225	43-48	G	237	650	550	100	186	89	39	89	96
	OWS 11 B	225	43-48	P	237	650	550	100	186	89	39	89	96
10.20OWS11PGAL	OWS 11 P	225	43-48	G	215	650	550	100	186	89	39	89	96
10.20OWS12PGAL	OWS 12 P	280	49-52	G	244	745	640	105	205	95	46	101	130
	OWS 12 B	280	49-52	G	263	745	640	105	205	95	46	101	130
02.174952HOL	OWS 12 P	280	49-52	P	244	745	640	105	205	95	46	101	130
	OWS 12 B	280	49-52	P	263	745	640	105	205	95	46	101	130
	OWS 13 B	360	54-58	G	298	785	660	125	250	108	54	114	180
10.20OWS13PGAL	OWS 13 P	360	54-58	G	275	785	660	125	250	108	54	114	180
	OWS 13 B	360	54-58	P	298	785	660	125	250	108	54	114	180
02.175458HOL	OWS 13 P	360	54-58	P	275	785	660	125	250	108	54	114	180
10.20OWS14PGAL	OWS 14 P	425	60-68	G	300	970	835	135	270	121	60	127	275
	OWS 14 B	425	60-68	G	330	970	835	135	270	121	60	127	275
	OWS 14 B	425	60-68	P	330	970	835	135	270	121	60	127	275
02.176068HOL	OWS 14 P	425	60-68	P	300	970	835	135	270	121	60	127	275
	OWS 15 B	460	72-76	G	380	1 150	1 000	150	300	133	76	146	440
10.20OWS15PGAL	OWS 15 P	460	72-76	G	355	1,15	1	150	300	133	76	146	440
	OWS 15 B	460	72-76	P	380	1 150	1 000	150	300	133	76	146	440
02.177276HOL	OWS 15 P	460	72-76	P	355	1,15	1	150	300	133	76	146	440
02.178186HOL	OWS 16 P	625	81-86	P	375	1,25	1,1	150	300	140	79	159	510
	OWS 16 B	625	81-86	P	397	1 250	1 100	150	300	140	79	159	510
10.20OWS16PGAL	OWS 16 P	625	81-86	G	375	1,25	1,1	150	300	140	79	159	510
	OWS 16 B	625	81-86	G	397	1 250	1 100	150	300	140	79	159	510

Code: OWS xx P - Pin , OWS xx B - Bolt

Finish: P-Painted, G-Galvanized
