General: Universal for lifting in any direction. The IPU10 vertical lifting clamp is used for the lifting, turning, moving or vertical transfer of sheet, plates, or fabrications from horizontal to vertical and down to horizontal (180°) as needed. The hinged hoisting eye allows for the clamp to place and lift the load from any direction, or with a multiple leg sling without sideloading the clamp.
Wide variety of jaw openings from 0 to 155 mm. Available in a variety of styles:
• IPU10 - Standard clamp for materials with a surface hardness to 37Rc (345 HB)
• IPU10J - Larger jaw opening.
• IPU10S - For use with Stainless Steel material.
• IPU10H - For use with materials with a surface hardness to 47Rc (450 HB).
• Full 180° turning range for material transfer, turning or moving.
• Lock open, lock closed ability with latch for pretension on material and then release of material.
• Optional IP-5000 Stinger assembly available (see page 382). Allows for easy connection between the clamp and hoist hook.

  • Märgistus: Logo, WLL, jaw capacity, serial number, proof load test date and CE-marking.
  • Pinnakate: Painted.
  • Märkus: Min load is 10% of WLL.
Vali allolevast tabelist sobivaim rida, seejärel lisa toode päringule
Tootekood WLL
tonn
I P Model. Lõug B (mm) C (mm) D (mm) E (mm) F (mm) G (mm) H (mm) J (mm) K (mm) Kaal
kg
CAD
16.012702275 0,5 0.5-IPU10S 0-16 44 130 216 40 115 42 28 - 11 1,9
16.012702263 1 1-IPU10S 0-20 45 139 225 40 127 41 38 - 11 2,4
16.012702277 2 2-IPU10S 0-35 78 201 368 70 188 64 55 - 16 8,5
16.012702265 3 3-IPU10S 0-40 100 253 436 75 222 78 60 - 20 14,8
16.012702267 4,5 4.5-IPU10S 0-40 100 253 436 75 227 82 65 - 20 16
16.012702269 6 6-IPU10S 0-50 126 302 525 80 292 84 95 44 20 24
16.012702271 9 9-IPU10S 0-50 126 325 552 80 310 92 104 44 20 29,5
16.012702279 12 12-IPU10S 0-54 160 392 616 80 433 121 137 41 25 57
