Red Rooster
General: The RED ROOSTER Mini Air Chain Hoists are besides industrial use also very suitable for "Material Handling". Due to the low weight these
hoists are very suitable for service applications. Special for use in tank cleaning installations we recommend stainless steel chain.
Standard features:
- Low weight and therefore very mobile, easy mounting
- Precise variable speed control (cord - and pendant control)
- Very compact design
- Robust aluminum housing
- Air motor is cooled by the exhaust air (internal)
- Cord control or pendant control
- Low noise level
- Mechanical endstop system
Optional features:
- Marine Specification/Corrosion resistant
- Paint systems from C2 - Industrial to C5 - Offshore specification (Red finish as standard. Other RAL colours available on request)
- Choice of pendants
- Radio control pendant for electro pneumatic controls
- Control systems
- Chain collectors (PVC, galvanised or stainless steel)
- Various types of hook or clevis available
- Air supply systems and valves
- Piped away exhaust air
- In house design for "specials"
- Festoon systems
- Main air shut off valve
- ATEX - According to EC Directive 94/9/EC (Ex Classification)
Vali allolevast tabelist sobivaim rida, seejärel lisa toode päringule
Tootekood Kood WLL
tonn
Working pressure (bar) Keti languste arv Tõstekiirus lastita (m/min) Tõstekiirus lastiga (m/min) Lowering speed with load m/min air consumption lifting I/sec air consumption lowering I/sec air connection " BSPT minimum hose diam " hose additional metre hol kg Kaal
kg
CAD
16.23TCR-250C TCR-250C 0,276 6 1 (4x 12mm RTS) 19 9,3 17,9 11,7 15 3/8" 1/2" 0,35 7
16.23TCR-250DPE TCR-250DPE 0,276 6 1 (4 x 12mm RTS) 17,2 8,1 13 11,7 15 3/8" 1/2" 0,35 7
16.23TCR-500C2 TCR-500C2 & TCR-500DP2 0,551 6 2 (4 x 12 mmRTS) 9,5 4,6 9 11,7 15 3/8" 1/2" 0,7 9
