Electric chain hoist with hook suspension

General: The ER2 Electric Chain Hoists are durable, safe and easy to use hoists. It has a top hook or overhead mounting suspension, aluminium die-cast body, electromagnetic brake and a canvas chain container.
It lifts from 10 tons up to 20 tons.

Standard configuration:
- 400 V/50 Hz
- Frequency inverter for 2 lifting speeds
- CH-Meter: operating hours/number of starts
- Ergonomic push button control
- Upper-lower limit switch
- Nickel-plated load chain class grade 80 (DAT) in accordance with Norm EN 818-7
- Thermal protector
- Carbon friction clutch> 400 V/50 Hz

Options:
- 500 V/Contactor control
- 230 V/50 Hz/60 Hz, 3 phase
- Rubber bumpers for motorized trolleys
- Additional mechanical brake
- Electrical overload limiter
- Acoustic overload signal
- Radio remote control
- Variable speed control
- Level limit switch
- Steel chain container
- Trolley versions: motorized, geared and plain

Vali allolevast tabelist sobivaim rida, seejärel lisa toode päringule
Kood WLL
tonn
Testkoormus (ton) Keti languste arv Lifting motor Output (kW) Lifting motor Rating (%ED) ISO/FEM klass Lisakaal 1m tõstekõrguse kohta Load chain (mm) x falls Kaal
kg
CAD
ER2-100IS 10 12,5 4 3,5x2 40/20 M4/1Am 11 11,2 x 31,3 303
ER2-150IS 15 18,8 6 3,5x2 40/20 M4/1Am 17 11,2 x 31,3 404
ER2-200IS 20 25,0 8 3,5x2 40/20 M4/1Am 22 11,2 x 31,3 476
* Note: The high speed is present to the maximum speed at the KITO factory in Japan. The low speed can be increased or respectively reduced.

CAD fail

CAD faili alla laadimiseks palun valige vastav toode ülalolevast tabelist ning vajutage "Laadi CAD" nupule. Peale CAD faili laadimist saate selle alla laadida.

Laadi CAD
Laadi alla
WLL
Kood Tõstekiirus*(m/min)
Min. kõrgus C
D
a
b
w
g
tons
    50Hz kõrge 50Hz madal
mm
mm
mm
mm
mm
mm
10
ER2-100IS
Reguleeritav 3,3 0,6
0,3
1370
1210
798
849
956
80
15
ER2-150IS
Reguleeritav 2,2 0,4
0,2
1595
1520
798
1022
1129
86
20
ER2-200IS
Reguleeritav 1,7 0,3
0,2
1710
1600
798
1198
1305
102
