The Ropeblock closed spelter socket CSS designed with mechanical values (Charpy-V > 42 joule / - 20° C) for though and low temperature use.
All sockets have a 100% efficency on the MBL of the steel wire rope but are limited to the MBL of the socket.
The CSS sockets are Type Approved by DNV and Lloyd’s Register.
- Material: Quenched and tempered cast steel.
- Marking: According to standard, CE-marked
- Temperature range: - 40°C to + 110°C - Use at higher temperatures possible with reduction of WLL.
- Finish: Galvanized (G) or painted blue (P).
- Standard: EN 10204
