General: Chain for lashing of timber on road vehicle.
Power test: 60% Of breaking force.

  • Material: Alloy steel grade 8.
  • Marking: One link per m chain is marked with grade.
  • Finish: Painted.
  • Standard: EN 12195-3
  • Note: Not to be heat-treated.
  • Warning: Not for lifting.
Hl [Black]_225mm
HLM_e_225mm
Select a row from the table below, then click the add to quote button
Art No Code LC (kN) LC (daN) Min. breakingforce
kN
Breaking force (kP) D (mm) E (mm) H (mm) Weight
kg/m
CAD
14.14LLP06.8 LLP-6-8 22 2 200 45,2 4 609 6 35 10 0,6
14.14LLP09.8 LLP-9-8 51 5 100 102 10 401 9 53 15 1,4
14.14LLP11.8 LLP-11-8 76 7 600 154 15 703 11 64 18 2,1
14.14LLP13.8 LLP-13-8 102 10 200 212 21 617 13 80 25 2,6
14.14LLP16.8 LLP-16-8 163 16 300 322 32 834 16 88 27 4,6
* LC = Lashing capacity, safety factor 2:1.
